BOKL Series Breakout Kits

250uM fiber in 2 or 3mm tubing

  • Introduction

    Opticonx BOKL Series Breakout Kits are designed to quickly and easily breakout and directly terminate up to 24 250uM fibers with 2.0mm color coded tubing or 12 250uM fibers with 3.0mm color coded tubing. Each of the 250uM buffered fibers are routed into individual color coded tubes via protective housing for identification, protection, fiber management and direct termination with industry standard LC, SC, ST and other industry standard connectors.

    Application:
    Fiber identification, management/routing, protection and direct termination of the individual 250uM buffered fibers in 2.0mm or 3.0mm tubing.

    Features/Benefits:
    No special tools required – Easily identified color coded tubing – Fits any manufacturer’s cable – Installs in minutes – Protects and manages bare fiber – Terminates any/all industry standard connectors

    Kit components:

    Cable body, breakout body, cable cover, screws and adhesive shrink tubing

    Standard tubing length is 36″
    Custom lengths available

    All Opticonx products are made in the USA.

  • Downloads

    BOKL Series

ORDERING INFORMATION

DESCRIPTION PART NUMBER
6 fiber kit for 250uM buffered fiber in 2.0mm tubing BOKL-06/2.0/36
8 fiber kit for 250uM buffered fiber in 2.0mm tubing BOKL-08/2.0/36
12 fiber kit for 250uM buffered fiber in 2.0mm tubing BOKL-12/2.0/36
12 fiber duplex kit for 250uM buffered fiber in 2.0mm tubing BOKLD-12/2.0/36
24 fiber kit for 250uM buffered fiber in 2.0mm tubing BOKL-24/2.0/36
6 fiber kit for 250uM buffered fiber in 3.0mm tubing BOKL-06/3.0/36
8 fiber kit for 250uM buffered fiber in 3.0mm tubing BOKL-08/3.0/36
12 fiber kit for 250uM buffered fiber in 3.0mm tubing BOKL-12/3.0/36
